- Compatible with TRIAC dimming.
- Flicker-free solution.
- THD compliance, surge withstand, conducted emissions compliance..
FF Linear Series
ODM Customization
Product Description
| P/N | Size | Input | Power | PF | Flux | Efficiency | CCT | CRI | Dimming |
| mm | Vac | W | - | LM | LM/W | K | - | - | |
| RL-HM280×40A2801H016-827FF | 280×40 | 230 | 16 | 0.9 | 1440 | 90 | 2700 | 80 | TRIAC |
| RL-HM280×40A2801H016-830FF | 1520 | 95 | 3000 | Flicker-free | |||||
| RL-HM280×40A2801H016-835FF | 1552 | 100 | 3500 | ||||||
| RL-HM280×40A2801H016-840FF | 1600 | 110 | 4000 | ||||||
| RL-HM280×40A2801H016-850FF | 1600 | 110 | 5000 | ||||||
| RL-HM280×40A2801H016-857FF | 1600 | 100 | 5700 | ||||||
| RL-HM280×40A2801H016-927FF | 280×40 | 230 | 16 | 0.9 | 1290 | 80 | 2700 | 90 | TRIAC |
| RL-HM280×40A2801H016-930FF | 1360 | 86 | 3000 | Flicker-free | |||||
| RL-HM280×40A2801H016-935FF | 1424 | 89 | 3500 | ||||||
| RL-HM280×40A2801H016-940FF | 1600 | 100 | 4000 | ||||||
| RL-HM280×40A2801H016-950FF | 1600 | 100 | 5000 | ||||||
| RL-HM280×40A2801H016-957FF | 1520 | 95 | 5700 | ||||||
| P/N | Size | Input | Power | PF | Flux | Efficiency | CCT | CRI | Dimming |
| mm | Vac | W | - | LM | LM/W | K | - | - | |
| RL-LM280×40A1402H009-827FF | 280×40 | 230 | 9 | 0.9 | 810 | 90 | 2700 | 80 | TRIAC |
| RL-LM280×40A1402H009-830FF | 855 | 95 | 3000 | Flicker-free | |||||
| RL-LM280×40A1402H009-835FF | 900 | 100 | 3500 | ||||||
| RL-LM280×40A1402H009-840FF | 990 | 110 | 4000 | ||||||
| RL-LM280×40A1402H009-850FF | 990 | 110 | 5000 | ||||||
| RL-LM280×40A1402H009-857FF | 900 | 100 | 5700 | ||||||
| RL-LM280×40A1402H009-927FF | 280×40 | 230 | 9 | 0.9 | 720 | 80 | 2700 | 90 | TRIAC |
| RL-LM280×40A1402H009-930FF | 774 | 86 | 3000 | Flicker-free | |||||
| RL-LM280×40A1402H009-935FF | 800 | 89 | 3500 | ||||||
| RL-LM280×40A1402H009-940FF | 900 | 100 | 4000 | ||||||
| RL-LM280×40A1402H009-950FF | 900 | 100 | 5000 | ||||||
| RL-HM280×40A2801H016-957FF | 855 | 95 | 5700 |
