Lens with different light-emitting angle selections;
Best wall washing effect;
Flexibility, lamp can be bent and disassembled;
Good waterproof design can get IP67;
Suitable for indoor and outdoor use, can be used as decorative lighting, such as shopping malls, buildings, advertising lights, etc.
| Waterproof class | Product specification | Product model | LED package model | LED | Luminous Angle ° | actuate | Voltage(V) | Bead quantity /M | Light efficiency （LM/W) | Luminous flux/M±10% | Power/M | ||
| Rendering finger | SDCM | CCT | |||||||||||
| IP67 | singular | RL-FV2420030283520-8XX-WWWA2205 | 2835 | 80/90 | <3 | 2700-6500K | 15° /30°/60°/30x45° /25P20° | Constant voltage | 24V | 30LED/M | 100-110LM/W | 2000-2200lm/M | 20W/m |
| singular | RL-FV2420042283520-8XX-WWWA2205 | 2835 | 80/90 | <3 | 2700-6500K | Constant voltage | 24V | 42LED/M | 120-130LM/W | 2400-2600lm/M | 20W/m | ||
| singular | RL-FV2420048283520-8XX-WWWA2205 | 2835 | 80/90 | <3 | 2700-6500K | Constant voltage | 24V | 48LED/M | 140-150LM/W | 2800-3000lm/M | 20W/m | ||
| double | RL-FV2420042303020-8CW-WWWA2205 | 3030CW | 80/90 | <3 | 2700K+6500K | Constant voltage | 24V | 42LED/M | 120-130LM/W | 2400-2600lm/M | 20W/m | ||
| RGB | RL-FV2420042303020-RGB-WWWA2205 | 3030RGB | / | / | R:620-630nm G:520-530nm B:465-475nm | Constant voltage | 24V | 42LED/M | R:15lm/W G:85lm/W B:30lm/W | 800lm/M | 20W/m | ||
| SPI | RL-FV2420036303020-SPI-WWWA2205 | 3030RGB | / | / | R:620-630nm G:520-530nm B:465-475nm | Constant voltage | 24V | 36LED/M | R:15lm/W G:85lm/W B:30lm/W | 600lm/M | 14W/m | ||
| DMX512 | RL-FV2420036303020-DMX-WWWA2205 | 3030RGB | / | / | R:620-630nm G:520-530nm B:465-475nm | Constant voltage | 24V | 36LED/M | R:15lm/W G:85lm/W B:30lm/W | 750lm/M | 18W/m | ||
| DMX512 | RL-FV2420036505020-DMX-WWWA2205 | 5050RGBW | / | / | R:620-630nm G:520-530nm B:465-475nm | 30° /35°/60°/30x45° /35x65° | Constant voltage | 24V | 36LED/M | R:23lm/W G:51lm/W B:13lm/W W：58lm/W | 550lm/M | 20W/m | |
| singular-Constant current | RL-FC2420042283520-8XX-WWWA2205 | 2835 | 80/90 | <3 | 2700-6500K | 15° /30°/60°/30x45° /25P20° | Constant voltage IC | 24V | 48LED/M | 110-120LM/W | 2200-2400lm/M | 20W/m | |
| 48V-DMX512 | RL-FV2420036505020-DMX-WWWA2205 | 5050RGBW | 80/90 | <3 | R:620-630nm G:520-530nm B:465-475nm W：2700-6500K | 30° /35°/60°/30x45° /35x65° | Constant voltage | 48V | 48LED/M | R:23lm/W G:51lm/W B:13lm/W W：58lm/W | 500lm/M | 18W/m | |
